Section 1 Requirements Specification Document
JaMB
Preliminary
Design
Document
September 29th
2003
Courtney Arnold Mable Flickinger
Brandon Toone Susan Glaus
Table Of Contents
I. Preliminary Design Document
A.
Structure Charts . . . . . . . . . .
. . . . . . . . . . . . . . . . 2.1
B.
Data Dictionary . . . . . . . . . . . . . . .
. . . . . . . . . . . 2.2
C.
Module Design
. . . . . . . . . . . . . . . . . . . . . . . . . . 2.3
D.
Major Data Structures . . . . . . . . . . . . . . . . . . . . 2.4
2.1 Structure Charts
2.2 Data Dictionary
Bonuses
· Complete Trip of 700 Miles Bonus: Bonus of 400 points when winner completes a trip of 700 miles.
o = 400
· Coupe Fourre Bonus: Bonus of 300 points given to a player when a safety is played after a hazard card was placed.
o = 300
· Delayed Action Bonus: Bonus of 300 points given to possessor if trip is completed and no more cards exist in the Draw Pile.
o = 300
· Extension Bonus: Bonus of 200 points to whichever player completes the extended length of 1,000 miles.
o = 200
· Safe Trip Bonus: Bonus of 300 points if winner completes a trip without playing any 200 mile card.
o = 300
· Shutting Out Bonus: Bonus of 500 points after a completion of a 1000 mile trip and before opponent is able to play any Distance Card.
o = 500
General
· Battle Pile: Area where Hazard Cards and Remedy Cards are played.
o = {0{Hazard Cards}18 | 0{Remedy Cards}38} |
{0{Hazard Cards}18 +0{Remedy Cards}38}
· Digit: A number value.
o = {0|1|2|3|4|5|6|7|8|9}
· Discard Pile: Area for cards already played.
o
= 0{Card}101
· Draw Pile: Area containing all cards from which each player takes one per draw.
o
= 0{Card}101
· Hand Pile: Cards in the players control. No more than 5.
o
= 0{Card}5
· Mile: A unit of length between point A and point B, options are 25, 50, 75, 100, 200.
o = {25|50|75|100|200}
· Speed Pile: 2 piles (one for each player) where Speed Limit Cards and End of Limit Cards are placed.
o = {0{Speed Limit Card}4 | 0{End of Limit Card}6 } |
{0{Speed Limit Card}4 + 0{End of Limit Card}6 }
· Trip: Distance traveled.
o
= 0{Digit}4
· Completed Trip: The definition of a complete trip is 700 miles or 1000 miles if an extension was called.
o = {700 | 1000}
Distance
· Distance Pile: Area to keep track of distance traveled. One per player (user/opponent).
o
= 0{Distance Cards}46
· Distance Card: 46 cards representing a distance in miles.
o = Card
Hazards
· Hazard Card: 13 cards representing a road hazard occurred. Used against opponent.
o = Card
· Accident Card: 2 Hazard Cards representing player incurred an accident.
o = Card
· Flat Tire Card: 2 Hazard Cards representing that the receiver has a flat tire and cannot continue to place Distance Cards.
o = Card
· Out of Gas Card: 2 Hazard Cards representing that the receiver is out of gas and cannot move until remedied.
o = Card
· Speed Limit Card: 3 Hazard Cards used to keep opponent from using a Distance Card greater than 50.
o = Card
· Stop Card: 4 Hazard Cards forcing to receiver to stop playing Distance Cards.
o = Card
Remedies
· Remedy Card: 38 cards used to recover from a Hazard Card played against possessor.
o = Card
· End of Limit Card: 6 Remedy Cards representing an end to a speed limit set by opponent.
o = Card
· Gasoline Card: 6 Remedy Cards representing possessor has gas.
o = Card
· Repair Card: 6 Remedy Cards used to counter an Accident Card.
o = Card
· Roll Card (Go): 14 Remedy Cards representing possessor can continue or begin laying down Distance Cards.
o = Card
· Spare Tire Card: 6 Remedy Cards used to remedy a Flat Tire Card previously played against possessor.
o = Card
Safeties
· Safety Area: Area where Safety Cards are played.
o
= 0{Safety Card}4
· Safety Card: 4 cards used for prevention of future hazards.
o = Card
· Driving Ace: 1 Safety Card preventing a future Accident Card for the possessor.
o = Card
· Extra Tank Card: 1 Safety Card preventing a future Out of Gas Hazard for the possessor.
o = Card
· Puncture Proof Card: 1 Safety Card preventing a future Flat Tire Hazard for the possessor.
o = Card
· Right of Way Card: 1 Safety Card used to prevent future Speed Limit Cards being played against possessor.
o = Card
2.3 Module Design
Title: Shuffle Deck
Module Id: 2.1.2.1
Purpose: This module shuffles the deck of cards.
Method: This module will call the shuffle method in the java.util collections class.
Usage: New Game
External References: None
Calling Sequence: Deck (O) Data structure representing the deck pile.
Input Assertion: None
Output Assertion: The output is assumed to hold six positive integer values.
Variables: Deck
Author: Susan Glaus
Remarks: None
Title: Reset Round Score
Module Id: 2.1.2.2
Purpose: This module resets the round score.
Method: This module erases the round score from memory and replaces with zeros.
Usage: New Game
External References: None
Calling Sequence: Round Score (O) Integer value of zero.
Input Assertion: None
Output Assertion: Round score is zero
Variables: Round score
Author: Susan Glaus
Remarks: None
Title: Deal 1 Card (User)
Module ID: 2.1.2.3.1
Purpose: Place one card in the Hand of Player 1 and displays on the GUI
Method: After updating Player1s hand this module must make a call to Update Display, which will be shown on screen
Usage: Deal Cards
External References: None
Calling Sequence: Card (I) Card to deal to player.
Input Assertion: Card is valid according to the rules of the game
Output Assertion: None
Variables: None
Author(s): Brandon Toone
Remarks: None
Title: Deal 1 Card (Opponent)
Module ID: 2.1.2.3.2
Purpose: Place one card in the Hand of Player 2 and displays on the GUI
Method: After updating Player 2s hand this module must make a call to Update Display, which will be shown on screen
Usage: Deal Cards
External References: None
Calling Sequence: Card (I) Card to deal to player.
Input Assertion: None
Output Assertion: None
Variables: None
Author(s): Brandon Toone
Remarks: None
Title: Turn
Module ID: 2.1.2.4
Purpose: To switch playing area to the user.
Method: This module allows the user to draw a card, play or discard a card, and specify when the turn is done.
Usage: New Game
External References: None
Calling Sequence: Player (I) The current player
Input Assertion: Player is an integer, 1 or 2.
Output Assertion: None
Variables: None
Author: Susan Glaus
Remarks: None
Title: Draw Card
Module ID: 2.1.2.4.1
Purpose: This module pops a card of the deck stack and passes it as an output.
Method: This module will remove a card from the top of the deck.
Usage: Turn
External References: None
Calling Sequence: Deck (I) A data structure holding cards to be used.
Card (O) An object that represents a card.
Input Assertion: Deck is assumed to be an array or stack of Cards.
Output Assertion: Card is assumed to be a card from the structure Deck.
Variables: Deck
Author(s): Courtney Arnold
Remarks: None
Title: Check if Move is Valid
Module ID: 2.1.2.4.2.1
Purpose: This module checks to see if the card being played can be played where it is being placed.
Method: This module will check the current requirement of the given pile to see if the given pile can accept the given card.
Usage: Play
External References: None
Calling Sequence: Card (I) Card to be played.
Pile State (I) The current state of the pile.
Validity (O) A boolean value, true if the card can be place and false if it cannot be placed
Input Assertion: Card is assumed to be a card structure.
Pile State is assumed to be an interger value.
Output Assertion: Validity is assumed to be a boolean value.
Variables: None
Author(s): Courtney Arnold
Remarks: None
Title: Play Card
Module ID: 2.1.2.4.2.2
Purpose: This module passes a card from the players hand to the selected pile.
Method: This module will remove the card from the player hand and will push the card to the top of the selected pile.
Usage: Play
External References: None
Calling Sequence: Card (I) Card to be removed from the player hand.
Piles (I) A data structure representing the piles.
Pile (I) An integer value.
Input Assertion: Card is assumed to be of the card structure.
Piles is assumed to be an array of the Pile data structures.
Pile is assumed to be a valid integer between 0 and 6.
Output Assertion: None
Variables: Piles A data structure representing the piles.
Author(s): Courtney Arnold
Remarks: None
Title: ChangePlayer
Module ID: 2.1.2.4.4.1
Purpose: Changes current player from player 1 to player 2 at the end of each turn.
Method: None
Usage: TurnDone
External References: None
Calling Sequence: Turn Done - (I) Confirms current turn is complete. Turn - (O) Starts next players turn.
Input Assertion: Current turn complete
Output Assertion: Next players turn
Variables: Current Player
Author(s): Mable Flickinger
Remarks: None
Title: Discard
Module ID: 2.1.2.4.3
Purpose: This module will remove the given card from play.
Method: This module will remove a Card from the players hand.
Usage: Turn
External References: None
Calling Sequence: Card (I) Card to be removed.
Input Assertion: Card is assumed to be a Card in the players hand.
Output Assertion: None
Variables: None
Author(s): Courtney Arnold
Remarks: None
Title: UpdateGUI
Module ID: 2.1.2.5
Purpose: Method called by various parts of the game to update the GUI when changes are made.
Method: Repaint
Usage: All
External References: None
Calling Sequence: None
Input Assertion: None
Output Assertion: Display refreshed
Variables: None
Author(s): Mable Flickinger
Remarks: None
Title: Quit
Module ID: 2.1.3
Purpose: Exits the game returning to the host system.
Method: None
Usage: File
External References: None
Calling Sequence: Exits game.
Input Assertion: None
Output Assertion: None
Variables: None
Author(s): Mable Flickinger
Remarks: None
Title: View Score
Module ID: 2.1.4
Purpose: Displays the games high score. Which is the sum of all the rounds which have been played since either starting or clearing/resetting the score.
Method: None
Usage: File
External References: None
Calling Sequence: High score - (I) File or variable containing the high score information. Display location - (O) The high score will be displayed to the game GUI.
Input Assertion: High score information.
Output Assertion: None
Variables: PreviousScore, CurrentScore
Author(s): Mable Flickinger
Remarks: None
Title: Reset Score
Module Id: 2.1.5
Purpose: This module resets the high score.
Method: This module erases the high score from memory and replaces with zeros.
Usage: File
External References: None
Calling Sequence: Score (O) Integer value of zero.
Input Assertion: None
Output Assertion: The high score zero.
Variables: High score
Author: Susan Glaus
Remarks: None
Title: Undo
Module Id: 2.1.6
Purpose: This module allows the user to go back to the previous step.
Method: This module will keep track of all moves and reset the card value that was most recently changes. The previous and current moves will be held in two undo objects. When the player selects undo this method swap the current move object with the previous move object.
Usage: File
External References: None
Calling Sequence: Previous Card (O) Data structure representing the previous card played.
Input Assertion: None
Output Assertion: None
Variables: Current move and previous move
Author: Susan Glaus
Remarks: None
Title: Instructions
Module ID: 2.2.1
Purpose: This module displays an instructions file when called from the menu
Method: None
Usage: Help
External References: None
Calling Sequence: Instructions file (I) The instructions file packaged with game. Display location (O) The instructions file will always be displayed to the game GUI
Input Assertion: A text file
Output Assertion: None
Variables: None
Author(s): Brandon Toone
Remarks: None
Title: About
Module ID: 2.2.2
Purpose: Display to the User; name, version number and authors of game
Method: None
Usage: Help
External References: None
Calling Sequence: About file (I) The file listing details of the game. Display location (O) The about file will always be displayed to the game GUI
Input Assertion: A text file
Output Assertion: None
Variables: None
Author(s): Brandon Toone
Remarks: None
Title: gameBoard
Module ID: 3.0
Purpose: This module contains the graphics that comprise the game board, including the images for the front and back of the cards, as well as the trip distance, etc.
Method: None
Usage: Display
External References: None
Calling Sequence: Mouse (I) User interaction with game.
Monitor (O) Update display of cards, trip, etc.
Input Assertion: None
Output Assertion: Part of the graphical user interface
Variables: Height, width, contents, etc.
Author(s): Mable Flickinger
Remarks: None
2.4 Major Data Structures
The major data structures are as follows:
One pile = ArrayList
Piles = an array of piles
Card = Object
Deck = pile
Section 3 The User Interface DocumentBack to JaMB Home
